| Level Sensor |
Piezoresistive Silicon with Hastelloy Sensor |
| Accuracy |
± 0.05 kPa |
| Normalization |
Automatic Temperature Compensation |
| Temp. Comp. Range |
-10ºC to 50ºC |
| Temperature Range |
Platinum Resistance Temperature Detector (RTD) |
| Temp. Sensor Accuracy |
± 0.05ºC |
| Temp. Sensor Resolution |
0.003ºC |
| Battery Life |
10 years (based on 1 reading/minute) |
| Clock Accuracy (typical) |
±1 minute/year (-20ºC to 80ºC) |
| Operating Temperature |
-20ºC to 80ºC |
| Maximum Readings |
40,000 sets of readings |
| Memory |
Continuous or Slate mode |
| Communication Speed |
9600 bps, 38,400 bps with USB optical reader |
| Com Interface |
Optical Infra-red: USB, RS-232, SDI-12 |
| Size |
22 mm x 159 mm (7/8" x 6.25") |
| Weight |
129 grams (4.5 oz.) |
| Corrosion Resistance |
Titanium based PVD coated body and superior corrosion resistant Hastelloy sensor |
| Other Wetted Materials |
Delrin, Viton®, 316L Stainless Steel |
| Sampling Modes |
Linear, Event & User-Selectable Schedule with Repeat Mode, Future Start, Future Stop, Real Time View |
| Measurement Rates |
0.125 second to 99 hours |
