Specifications
| Level Sensor | Piezoresistive Silicon with Hastelloy Sensor |
|---|---|
| Ranges | 15, 10, 20, 30, 100, 200 m |
| Accuracy | ± 0.05% FS |
| Normalization | Automatic Temp Compensation |
| Temp. Comp. Range | 0ºC to 50ºC |
| Temperature Sensor | Platinum Resistance Temperature Detector (RTD) |
| Temp. Sensor Accuracy | ± 0.05ºC |
| Temp. Sensor Resolution | 0.003ºC |
| Battery Life | 10 years (based on 1 reading/minute) |
| Clock Accuracy (typical) | ±1 minute/year (-20ºC to 80ºC) |
| Operating Temperature | -20ºC to 80ºC |
| Maximum # Readings | 40,000 sets of readings |
| Memory | Continuous or Slate mode |
| Communication Speed | 9600 bps, 38,400 bps with USB optical reader |
| Com Interface | Optical Infra-red: USB, RS-232, SDI-12 |
| Size | 22 mm x 159 mm (7/8" x 6.25") |
| Weight | 129 grams (4.5 oz.) |
| Corrosion Resistance | Titanium based PVD coated body and superior corrosion resistant Hastelloy sensor |
| Other Wetted Materials | Delrin, Viton, 316L Stainless Steel |
| Sampling Modes | Linear, Event & User-Selectable Schedule with Repeat Mode, Future Start, Future Stop, Real Time View |
| Measurement Rates | 0.125 second to 99 hours |
| Barometric Compensation | High accuracy, air-only, Barologger Edge |
